HMW 10.0 PHT – EN Winch ; When it comes to heavy-duty winches, one name stands out in the industry: Hammerwinch. Known for their exceptional quality, durability, and reliability, Hammerwinch has been a trusted brand for professionals in various fields. Among their impressive lineup of winches, the HMW 10.0 PHT – EN Winch truly shines as a powerhouse in its class.

Hammerwinch has always been at the forefront of innovation, constantly pushing the boundaries of what a winch can achieve. With the HMW 10.0 PHT – EN , they have once again raised the bar. This exceptional product is designed to tackle the toughest challenges and provide unmatched performance in demanding situations.

One of the key features that sets the HMW 10.0 PHT – EN apart is its impressive pulling capacity. With a remarkable maximum line pull of 10,000 kilograms, this winch can handle even the heaviest loads with ease. Whether you’re dealing with large machinery, off-road vehicles, or industrial equipment, the HMW 10.0 PHT – EN Winch has got you covered.

Standard

  • Roller Fairlead
  • Cable Tensioner
  • Manual Clutch

Hydraulic Inlets

  • G 1/2″

Optional

  • Air Clutch
  • IP67 – IP 68
  • PneumaticCable Tensioner

Mounting Bolts

  • 16 Pieces M16 8,8
,

General

Max. pulling capacity (kg/Ibs): 10000 kg (22040 Ibs)
Max. rope length (m/ft): 58.3 m (191 ft)
Max. rope length for EN (m/ft): 41.2 m (135 ft)
Recommended wire rope (mm/in): 16 mm (7/11″) 2160 Mpa
Hydromotor (cc/in³): 160 cc (9.6 in³)
Max. pump flow (L/min-g/min): 60 L/min (15.8 g/min)
Gear ratio: 28:1
Oil types and capactiy: 85 W 90 – 2L
Max. working pressure (bar/psi): 175 bar (2537 psi)
Winch (kg/Ibs): 197 kg (434 lbs)
Roller Fairlead (kg/lbs): 18 kg (39,6 lbs)
Cable Tensioner (kg/Ibs): 8 kg (17,6 lbs)

PN HMW 10.0 PHT-EN Manuel Clutch Shifter

PN HMW 10.0 PHT/P-EN Air Clutch Shifter

Technical Features

Winch Features

Rope Winding Layer Pulling Capacity (kg/lbs) Rope Speed (m/min-ft/min) Rope Lenght (m/ft)
1 10000/22040 7/23 12/39
2 8632/19026 8/27 25.4/83.3
EN 3 7594/16738 9/30 41.2/135
4 6779/14942 10/34 58.3/191

Pulling Capacity kg/lb Rope Speed m/min-ft/min Rope Lenght m/ft

Technical Document

  • Extra reinforced steel cast body.
  • Lightweight and strong design, high rope capacity.
  • Negative-acting hydraulic brake holding reinforced.
  • Dynamics, strong hydraulic motor and high strength cast drum.
  • EN 14492-1 : 2006 Power driven winches supported.
  • CE Machinery Directive 2006/42/EC
