HMW 30.0 PHT – EN Winch

HMW 30.0 PHT – EN Winch

Hammerwinch, a trusted manufacturer of top-quality winches, proudly presents the HMW 30.0 PHT – EN Winch. Built to handle the most demanding tasks, this winch combines extraordinary power, robust construction, and advanced features to deliver exceptional performance and reliability in a variety of applications.

Unmatched Pulling Capacity:

The HMW 30.0 PHT – EN Winch sets a new standard in pulling capacity with an impressive rating of 30,000 7 kilograms. With this exceptional power, it effortlessly handles heavy loads, making it suitable for industrial operations, heavy-duty recovery tasks, and challenging off-road adventures. No matter the task at hand, this winch is designed to tackle it with ease.

Robust and Durable Construction:

Hammerwinch is known for its commitment to durability, and the HMW 30.0 PHT – EN Winch exemplifies this philosophy. It is constructed with high-quality materials and built to withstand the harshest conditions and rigorous use. The winch’s robust construction ensures long-lasting reliability, making it an essential tool for professionals operating in demanding environments.

Standard

  • Cable Tensioner
  • Air Clutch

Hydraulic Inlets

  • G 3/4″

Optional

  • IP67 – IP 68
  • Pneumatic Cable

Mounting Bolts

  • 8 Pieces M24 8,8

General

Max. pulling capacity (kg/lbs): 30.000 kg (66120 Ibs)
Max. rope length (m/ft): 64.9 m (212 ft)
Max. rope length for EN (m/ft): 45.4 m (149 ft)
Recommended wire rope (mm/in): 26 mm (1”) 2160 Mpa Compact
Hydromotor (cc/in³): 160 cc (9.6 in³)
Max. pump flow (L/min-gal/min): 75 L/min (19.8 g/min)
Gear ratio: 114:1
Oil types and capactiy: 85 W 140 – 2,75 L
Max. working pressure (bar/psi): 190 bar (2755 psi)
Winch (kg/lbs): 585 kg (1289.3 lbs)
Cable Tensioner (kg/lbs): 9 kg (19 lbs)

PN HMW 30.0 PHT/P – EN Air Clutch Shifter

Technical Features

Winch Features

Rope Winding Layer Pulling Capacity (kg/lbs) Rope Speed (m/min-ft/min) Rope Lenght (m/ft)
1 30000/66120 3.6/11.8 13.2/43.3
2 25956/57209 4.1/13.4 27.6/90.5
EN 3 22872/50412 4.7/15.4 45.4/149
4 20443/45058 5.3/17.4 64.9/212

Pulling Capacity kg/lb Rope Speed m/ft min Rope Lenght m/ft

Technical Document

  • Extra reinforced steel cast body through the heat treatment and industrial design.
  • Light and robust design.
  • 100% Holding negative-acting hydraulic brake system.
  • Standard pneumatic rope unloading system.
  • Easy assembly, compact design and high torque hydromotor.
  • Three-stage planetary gear system.
  • EN 14492-1 : 2006 Power driven winches supported
  • CE Machinery Directive 2006/42/EC

HMW 30.0 PHT – EN Winch

HMW 30.0 PHT – EN Winch Technical Drawing
