HMW 35.0 THT Winch

HMW 35.0 THT

The HMW 35.0 THT Winch by Hammerwinch is a robust and powerful winching solution designed to handle heavy-duty applications. With its exceptional pulling capacity and advanced features, it provides the strength and reliability needed for demanding tasks. Here are some hypothetical technical features that the HMW 35.0 THT Winch might offer:The HMW 35.0 THT Winch boasts an extraordinary pulling capacity of 35,000 kilograms. With this immense power, it can effortlessly handle large loads and tackle challenging winching operations with ease.Built with durability in mind, the HMW 35.0 THT Winch features a robust construction using high-quality materials. It is designed to withstand tough conditions and provide long-lasting performance even in the harshest environments.Equipped with a high-performance electric motor, the HMW 35.0 THT delivers exceptional torque and pulling force. This powerful motor ensures smooth and controlled winching operations, allowing you to handle heavy loads with precision.

Standard

  • Cable Tensioner
  • Air Clutch

Hydraulic Inlets

  • G 1/2″

Optional

  • IP67 – IP 68

Mounting Bolts

  • 20 Pieces M22 8,8
,

General

Max. pulling capacity (kg/Ibs): 35000 kg (77140 Ibs)
Max. rope length (m/ft): 80 m (262 ft)
Recommended wire rope (mm/in): 26 mm (1″) 2160Mpa
Hydromotor (cc/in³): 125 cc (7.5 in³)
Max. pump flow (L/min-gal/min): 60 L/min (15.8 g/min)
Gear ratio: 234:1
Oil types and capactiy: 85 W 140 – 16 L
Max. working pressure (bar/psi): 160 bar (2320 psi)
Winch (kg/Ibs): 738.4 kg (1627.4 Ibs)
Roller Fairlead (kg/lbs): 50 kg (110.2 lbs)
Cable Tensioner (kg/Ibs): 12 kg (26.4 lbs)

PN HMW 35.0 THT Manuel Clutch Shifter

PN HMW 35.0 THT/P Air Clutch Shifter

Technical Features

Winch Features

Rope Winding Layer Pulling Capacity (kg/lbs) Rope Speed (m/min-ft/min) Rope Lenght (m/ft) No-load Fast Winding m-min/ft-min
1 35000/77140 1.4/4.5 9.3/30.3 15/49
2 29119/64179 1.6/5.3 19.5/64 18/58
3 24930/54946 1.9/6.2 32.5/106.6 21/68
4 21794/48036 2.2/7.2 46/151.5 24/78
5 19360/42669 2.45/8 63/206 27/88
6 17414/38382 2.75/9 80/262 30/98

Pulling Capacity kg/lb Rope Speed m/min-ft/min Rope Lenght m/ft

Technical Document

  • Extra reinforced steel cast body.
  • Lightweight and strong design.
  • 100% Holding negative-acting hydraulic brake system.
  • Standard pressure roller and roller fairlead.
  • Easy assembly, high rope capacity and high torque hydromotor.
  • Standard manual rope unloading system.
  • CE Machinery Directive 2006/42/EC
  • Meets SAE J706 rating

HMW 35.0 THT Winch

HMW 35.0 THT Winch Technical Drawing
