HMW 30.0 THT Winch

HMW 30.0 THT Winch

The HMW 30.0 THT Winch by Hammerwinch is a robust and reliable winching solution designed to handle heavy-duty applications. With its exceptional power and advanced features, it provides the strength and performance needed for demanding tasks. Here are some hypothetical technical features that the HMW 30.0 THT Winch might offer:

The HMW 30.0 THT Winch boasts a remarkable pulling capacity of 30,000 kilograms. This substantial power allows it to effortlessly handle large loads and tackle challenging winching operations with ease.

Built to withstand rugged environments, the HMW 30.0 THT features a robust construction using high-quality materials. It is designed to handle the harshest conditions and provide long-lasting durability.

Equipped with a high-performance electric motor, the HMW 30.0 THT delivers exceptional torque and pulling force. This powerful motor ensures smooth and controlled winching operations, even under heavy loads.

Standard

  • Cable Tensioner
  • Air Clutch

Hydraulic Inlets

  • G 1/2″

Optional

  • IP67 – IP 68

Mounting Bolts

  • 20 Pieces M22 8,8
,

General

Max. pulling capacity (kg/lbs): 30.000 kg (66.120 Ibs)
Max. rope length (m/ft): 80 m (262 ft)
Recommended wire rope (mm/in): 26 mm (1″) 1960Mpa
Hydromotor (cc/in³): 100 cc (6 in³)
Max. pump flow (L/min-gal/min): 60 L/min (15.8 g/min)
Gear ratio: 234:1
Oil types and capactiy: 85 W 140 – 16 L
Max. working pressure (bar/psi): 170 bar (2465 psi)
Winch (kg/lbs): 738.3 kg (1627.2 Ibs)
Roller Fairlead (kg/lbs): 50 kg (110.2 lbs)
Cable Tensioner (kg/lbs): 12 kg (26.4 lbs)

PN HMW 30.0 THT Manuel Clutch Shifter

PN HMW 30.0 THT/P Air Clutch Shifter

Technical Features

Winch Features

Rope Winding Layer Pulling Capacity (kg/lbs) Rope Speed (m/min-ft/min) Rope Lenght (m/ft) No-load Fast Winding m-min/ft-min
1 30000/66120 1.7/5.6 9.3/30.3 15/49
2 24959/55010 2/6.7 19.5/64 18/58
3 21368/47096 2.4/7.8 32.5/106.6 21/68
4 18681/41173 2.7/9 46/151.5 24/78
5 16594/36573 3/10 63/206 27/88
6 14926/32898 3.4/11.2 80/262 30/98

Pulling Capacity kg/lb Rope Speed m/min-ft/min Rope Lenght m/ft

Technical Document

  • Extra reinforced steel cast body.
  • Lightweight and strong design.
  • 100% Holding negative-acting hydraulic brake system.
  • Standard pressure roller and roller fairlead.
  • Easy assembly, high rope capacity and high torque hydromotor.
  • Standard manual rope unloading system.
  • CE Machinery Directive 2006/42/EC
  • Meets SAE J706 rating

HMW 30.0 THT Winch

HMW 30.0 THT Winch Technical Drawing
