HMW 4.3 PHT-EN Winch
EN Series
| Max. pulling capacity (kg/Ibs): | 4300 kg (9477 lbs) |
| Max. rope length (m/ft): | 48 m (157 ft) |
| Max. rope length for EN (m/ft): | 36 m (118 ft) |
| Recommended wire rope (mm/in): | 11 mm (4/9”) 1960 Mpa |
| Hydromotor (cc/in³): | 315 cc (19 in³) |
| Max. pump flow (L/min-g/min): | 60 L/min (15.8 g/min) |
| Gear ratio: | 5,6:1 |
| Oil types and capactiy: | 85 W 90 - 0,75 L |
| Max. working pressure (bar/psi): | 120 bar (1740 psi) |
| Winch (kg/Ibs): | 54 kg (119 Ibs) |
| Roller Fairlead (kg/lbs): | 6 kg (13,22 lbs) |
| Cable Tensioner (kg/Ibs): | 2,5 kg (5,51 lbs) |
PN HMW 4.3 PHT-EN Manuel Clutch Shifter
PN HMW 4.3 PHT/P-EN Air Clutch Shifter
Winch Features
Rope Winding Layer
Pulling Capacity
kg/lbs
Rope Speed
m/min-ft/min
Rope Lenght
m/ft
1
4300/9477
11/36
7/23
2
3657/8060
13/42
16/52
3
3181/7010
15/49
25/82
EN 4
2815/6204
17/55
36/118
5
2524/5564
19/62
48/157
Pulling Capacity kg/lb Rope Speed m/min-ft/min Rope Lenght m/ft
- Extra reinforced aluminium cast body through the heat treatment and industrial design.
- Light and robust design.
- 100% Holding negative-acting hydraulic brake system.
- Standard pressure roller and roller fairlead.
- Easy assembly, high rope capacity and high torque hydromotor.
- Standard manual rope unloading system.
- EN 14492-1 : 2006 Power driven winches supported.
- CE Machinery Directive 2006/42/EC
HMW 4.3 PHT-EN Winch 2D/3D Design
Order Form
Standard
Roller Fairlead
Cable Tensioner
Manual Clutch
Hydraulic Inlets
G 1/2"
Optional
Air Clutch
IP67 - IP 68
Mounting Bolts
8 Pieces M14 8,8
