Winch
HMW 40.0 THT Winch
| Max. pulling capacity (kg/Ibs): | 40000 kg (88169 Ibs) |
| Max. rope length (m/ft): | 75 m (246 ft) |
| Max. rope length for SAE (m/ft): | 59.5 m (195.3 ft) |
| Recommended wire rope (mm/in): | 28 mm (10/9") 2160 Mpa |
| Hydromotor (cc/in³): | 125 cc (7.5 in³) |
| Max. pump flow (L/min-gal/min): | 75 L/min (19.8 g/min) |
| Gear ratio: | 158:1 |
| Oil types and capactiy: | 85 W 140 - 16 L |
| Max. working pressure (bar/psi): | 210 bar (3045 psi) |
| Winch (kg/Ibs): | 755.4 kg (1665 Ibs) |
| Roller Fairlead (kg/lbs): | 50 kg (110.2 lbs) |
| Cable Tensioner (kg/Ibs): | 12 kg (26.4 lbs) |
PN HMW 40.0 THT Manuel Clutch Shifter
PN HMW 40.0 THT/P Air Clutch Shifter
Winch Features
Rope Winding Layer
Pulling Capacity
kg/lbs
Rope Speed
m/min-ft/min
Rope Lenght
m/ft
No-load Fast Winding
m-min/ft-min
1
40000/88169
2.5/8.3
8.6/28.2
15/49
2
32915/72545
3.1/10
18/59
18.1/59.4
3
27960/61625
3.6/12
30.5/100
21.4/70
4
24302/53563
4.2/13.7
43.5/142,6
24.5/80.4
SAE 4
21490/47366
4.7/15.4
59.5/195.3
27.8/91
6
19262/42454
5.3/17.3
75/246
31/101.7
Pulling Capacity kg/lb Rope Speed m/min-ft/min Rope Lenght m/ft
- Extra reinforced steel cast body.
- Lightweight and strong design.
- 100% Holding negative-acting hydraulic brake system.
- Standard pressure roller and roller fairlead.
- Easy assembly, high rope capacity and high torque hydromotor.
- Standard manual rope unloading system.
- CE Machinery Directive 2006/42/EC
- Meets SAE J706 rating
HMW 40.0 THT Winch 2D/3D Design
Order Form
Standard
Roller Fairlead
Cable Tensioner
Hydraulic Inlets
G 1/2"
Optional
IP67 - IP 68
Mounting Bolts
20 Pieces M22 8,8
